在气力输送的工业舞台上，仓泵犹如一位沉稳可靠的 “物料搬运大师”，默默承担着大量物料的储存与输送任务。看似简单的外形下，仓泵实则是由多个功能各异的部件精妙组合而成，每个部件都各司其职，共同奏响高效输送的 “交响乐”。接下来，就让我们深入仓泵内部，一探究竟。

　　On the industrial stage of pneumatic conveying, the bin pump is like a steady and reliable "material handling master", silently undertaking the task of storing and conveying a large amount of materials. Despite its seemingly simple appearance, the warehouse pump is actually composed of multiple components with different functions that are ingeniously combined. Each component performs its own function and plays a symphony of efficient transportation together. Next, let's delve into the interior of the warehouse pump and explore it thoroughly.

　　仓泵的主体是一个坚固的容器，这是它的 “躯干”，也是储存物料的核心空间。这个容器通常采用高强度的钢材焊接而成，形状多为圆柱形或方柱形，能够承受较大的内部压力。为了确保容器的密封性，其各个连接部位经过精细处理，比如采用密封垫片、焊接密封等方式，防止在输送过程中出现物料泄漏或气体外泄的情况。同时，容器的内壁会根据输送物料的特性进行特殊处理，对于容易磨损的物料，内壁可能会加装耐磨衬里，延长容器的使用寿命；而对于腐蚀性较强的物料，内壁则会进行防腐涂层处理，避免容器被腐蚀损坏。

　　The main body of the warehouse pump is a sturdy container, which serves as its "torso" and the core space for storing materials. This container is usually made of high-strength steel welded together, and its shape is mostly cylindrical or square cylindrical, which can withstand significant internal pressure. In order to ensure the sealing of the container, its various connecting parts are finely processed, such as using sealing gaskets, welding seals, etc., to prevent material leakage or gas leakage during transportation. At the same time, the inner wall of the container will be specially treated according to the characteristics of the conveyed material. For materials that are prone to wear, wear-resistant lining may be added to the inner wall to extend the service life of the container; For materials with strong corrosiveness, the inner wall will be treated with anti-corrosion coating to prevent the container from being corroded and damaged.

　　进料阀是仓泵的 “入口守卫”，负责控制物料进入仓泵的过程。常见的进料阀有闸板阀、蝶阀等类型。闸板阀通过闸板的上下移动实现开闭，当闸板提升时，通道打开，物料依靠重力或外部推力进入仓泵；闸板落下时，与阀座紧密贴合，阻止物料和气体通过，保证仓泵内部的密封性。蝶阀则是以圆形蝶板为启闭件，绕阀杆轴线旋转来控制阀门开闭，其结构紧凑，操作灵活，能够快速完成进料过程。在进料阀工作时，会与仓泵的控制系统联动，当接收到进料信号时自动开启，在仓泵内物料达到设定量后及时关闭，确保进料过程准确、高效。

　　The feed valve is the "inlet guard" of the bin pump, responsible for controlling the process of materials entering the bin pump. Common types of feed valves include gate valves, butterfly valves, etc. The gate valve opens and closes by the up and down movement of the gate. When the gate is lifted, the channel opens and the material enters the bin pump by gravity or external thrust; When the gate plate falls, it tightly adheres to the valve seat, preventing materials and gases from passing through and ensuring the sealing inside the bin pump. Butterfly valves use circular butterfly plates as opening and closing components, rotating around the axis of the valve stem to control valve opening and closing. They have a compact structure, flexible operation, and can quickly complete the feeding process. When the feed valve is working, it will be linked with the control system of the bin pump. When it receives the feed signal, it will automatically open and close in a timely manner when the material in the bin pump reaches the set amount, ensuring accurate and efficient feeding process.

　　出料阀是仓泵的 “出口指挥官”，决定着物料从仓泵输出的节奏。与进料阀类似，出料阀也有多种形式，球阀在其中较为常用。球阀的球体上设有圆形通道，通过球体的旋转来控制通道的开闭。当球体上的通道与管道对齐时，阀门开启，在压缩空气的推动下，仓泵内的物料从通道排出进入输送管道；球体旋转 90 度后，通道被截断，阀门关闭，停止物料输送。出料阀的密封性能至关重要，良好的密封能够保证在仓泵充压过程中气体不会泄漏，确保物料在压力作用下顺利输送。同时，出料阀的开闭动作需要与整个输送流程精准配合，以实现物料的稳定输出。

　　The discharge valve is the "outlet commander" of the bin pump, determining the rhythm of material output from the bin pump. Similar to the feed valve, there are also various forms of discharge valves, among which ball valves are more commonly used. The ball valve has a circular channel on its sphere, which is controlled to open and close by the rotation of the sphere. When the channel on the sphere aligns with the pipeline, the valve opens, and under the push of compressed air, the material in the bin pump is discharged from the channel into the conveying pipeline; After the sphere rotates 90 degrees, the channel is cut off, the valve is closed, and material transportation is stopped. The sealing performance of the discharge valve is crucial. Good sealing can ensure that gas will not leak during the pressurization process of the bin pump, ensuring smooth transportation of materials under pressure. At the same time, the opening and closing action of the discharge valve needs to be precisely coordinated with the entire conveying process to achieve stable material output.

　　压缩空气管路系统是仓泵的 “动力输送线”，为物料输送提供动力源泉。它由一系列管道、阀门和连接件组成，将压缩空气从气源引入仓泵内部。在仓泵进料阶段，压缩空气管路处于关闭状态；当进料完成后，打开相关阀门，压缩空气进入仓泵，使内部压力升高。这些压缩空气不仅推动物料从出料阀排出，还会在输送管道内形成气流，携带物料沿着管道输送至目的地。为了保证压缩空气的质量和压力稳定，管路系统中通常会安装过滤器、减压阀等装置。过滤器可以去除压缩空气中的杂质、水分和油污，防止这些物质对仓泵和输送管道造成损害；减压阀则用于调节压缩空气的压力，使其符合仓泵的工作要求，避免压力过高或过低影响物料输送效果。

　　The compressed air pipeline system is the "power transmission line" of the bin pump, providing a power source for material transportation. It consists of a series of pipes, valves, and connectors that introduce compressed air from the air source into the interior of the bin pump. During the feeding stage of the bin pump, the compressed air pipeline is in a closed state; After the feeding is completed, open the relevant valves and compressed air enters the bin pump to increase the internal pressure. These compressed air not only push the material out of the discharge valve, but also form an airflow in the conveying pipeline, carrying the material along the pipeline to the destination. In order to ensure the quality and pressure stability of compressed air, devices such as filters and pressure reducing valves are usually installed in pipeline systems. Filters can remove impurities, moisture, and oil stains from compressed air, preventing these substances from causing damage to the bin pump and conveying pipeline; The pressure reducing valve is used to regulate the pressure of compressed air to meet the working requirements of the bin pump, avoiding excessive or insufficient pressure that affects the material conveying effect.

　　仓泵的控制系统是整个设备的 “智慧大脑”，协调各个部件有序工作。它由传感器、控制器和执行机构等部分组成。传感器负责实时监测仓泵的各项运行参数，如仓内压力、料位高度、阀门开闭状态等，并将这些数据传输给控制器。控制器根据预设的程序和逻辑，对传感器传来的数据进行分析处理，判断仓泵的工作状态是否正常。当出现异常情况时，如仓内压力过高、料位异常等，控制器会及时发出报警信号，并采取相应的措施，如停止进料、关闭阀门等，保障设备和人员安全。同时，控制器还会根据设定的流程，控制进料阀、出料阀和压缩空气管路阀门的开闭，以及压缩空气的通入和停止，实现仓泵进料、输送等过程的自动化操作，提高工作效率和准确性。

　　The control system of the warehouse pump is the "smart brain" of the entire equipment, coordinating the orderly operation of various components. It consists of sensors, controllers, and actuators. Sensors are responsible for real-time monitoring of various operating parameters of the warehouse pump, such as pressure inside the warehouse, material level height, valve opening and closing status, etc., and transmitting these data to the controller. The controller analyzes and processes the data transmitted by the sensors according to the preset program and logic, and determines whether the working status of the bin pump is normal. When abnormal situations occur, such as high pressure in the warehouse or abnormal material level, the controller will promptly issue an alarm signal and take corresponding measures, such as stopping feeding, closing valves, etc., to ensure the safety of equipment and personnel. At the same time, the controller will also control the opening and closing of the feed valve, discharge valve, and compressed air pipeline valve according to the set process, as well as the inlet and outlet of compressed air, to achieve automated operation of the bin pump feeding, conveying, and other processes, improving work efficiency and accuracy.

　　此外，仓泵还配备有一些辅助部件，如安全阀、压力表等。安全阀是仓泵的 “安全卫士”，当仓内压力超过设定的安全值时，安全阀自动开启，释放部分气体，降低仓内压力，防止仓泵因压力过高发生爆炸等危险事故。压力表则是操作人员观察仓内压力的 “眼睛”，通过直观显示仓内压力数值，方便操作人员掌握仓泵的工作状态，及时调整运行参数。

　　In addition, the warehouse pump is also equipped with some auxiliary components, such as safety valves, pressure gauges, etc. The safety valve is the "safety guard" of the warehouse pump. When the pressure inside the warehouse exceeds the set safety value, the safety valve automatically opens, releasing some gas, reducing the pressure inside the warehouse, and preventing dangerous accidents such as explosions caused by high pressure in the warehouse pump. The pressure gauge is the "eye" for the operator to observe the pressure inside the compartment, and by intuitively displaying the pressure value inside the compartment, it is convenient for the operator to grasp the working status of the compartment pump and adjust the operating parameters in a timely manner.

　　仓泵正是由主体容器、进料阀、出料阀、压缩空气管路系统、控制系统以及众多辅助部件相互配合、协同工作，才得以高效地完成物料的储存与输送任务。这些部件就像精密钟表中的零件，每一个都不可或缺，共同构建起仓泵强大而可靠的功能体系，在工业生产的物料输送环节中发挥着重要作用。

　　The warehouse pump is composed of the main container, feed valve, discharge valve, compressed air pipeline system, control system, and numerous auxiliary components working together to efficiently complete the storage and transportation tasks of materials. These components are like parts in precision watches, each indispensable, together building a powerful and reliable functional system for the warehouse pump, playing an important role in the material conveying process of industrial production.
